ELECTRIC ACTUATORS - SERIES 85

MOD. VB270

Technical specifications

SIZE	PATTERN ISO 5211	CH	A	B	C	D	E	F	G	H	I	L	M	N	O	ØP	Q
VB270	F07-F10	22	8.74	9.19	3.03	6.69	7.17	2.03	2.13	1.58	0.95	2.76	4.02	5/16-18 UNC 2BX0.75	3/8-16 UNC 2BX0.75	4.33	4.53

Electrical diagrams

Certifications

CSA International

Available media and videos

PNEUMATIC AND ELECTRIC ACTUATED VALVE PACKAGES

CAT245100 USA RB-VP-VB
